JK and WJ Axle Geometry

[Root Moose]

Does anyone know off hand if the JK and WJ axles share the same control arm mounting brackets on the axles?

Wondering if JK axles are an "easy" swap onto a WJ...

TIA



[Amauri]

I don't believe they do. I have a friend who is swapping in jk 44's into his wj i will check with him and let you know.



[Root Moose]

Cool - thanks!



[gprsdlyt]

iron rock offroad makes a kit for this swap. not sure how much work is involved. look in the WJ products section.
-website down at the moment for maint. or id link it.



[Backwoods Rambler]

I thought I read of a guy on colorado4x4.org who swapped JK axles directly into his XJ. Not sure if that's any indication, but I thought WJ & XJ axles were swappable (with the exception of bolt patterns of course)



[Ford Prefect]

Is the JK axle not significantly wider than the WJ?

or is that the point?



[w squared]

Front axle:

http://www.ironrockoffroad.com/Merchant2/merchant.mvc?Screen=PROD&Store_Code=IROR&Product_Code=IR-WJKFA


Rear axle:

http://www.ironrockoffroad.com/Merchant2/merchant.mvc?Screen=PROD&Store_Code=IROR&Product_Code=IR-WJKRA

Spendy conversion...but axles are never cheap. On the plus side, you've getting a trussed JK 44. Throw in a set of sleeves in the front, gusset the C's, and some chromo shafts and you'll be ready to run 37's...or keep it at 35's and your axles will last a long time, even under abusive conditions.



[Amauri]

Does anyone know off hand if the JK and WJ axles share the same control arm mounting brackets on the axles?

Wondering if JK axles are an "easy" swap onto a WJ...

TIA

I spoke with my friend tonight and they do not.



[Amauri]

Is the JK axle not significantly wider than the WJ?

or is that the point?

they are only slightly wider 1.75".



[Amauri]

I thought I read of a guy on colorado4x4.org who swapped JK axles directly into his XJ. Not sure if that's any indication, but I thought WJ & XJ axles were swappable (with the exception of bolt patterns of course)

i believe tj, zj, and xj axles swappable. Not sure about xj and jk axles being swappable i don't think so(at least not easily).



[w squared]

XJ's have rear leaf springs. JK's have rear coil springs.

Even if track width was the same (JK's are wider), the difference in springs would mean that it couldn't be a straight swap. It may be a relatively "easy" swap, but you're still going to be making some substantial changes to either the JK axle or your XJ.



[Amauri]

lol i forgot xj's had leafs in the rear



[Cole]

Wondering if JK axles are an "easy" swap onto a WJ...

TIA

Well, the rear upper of a WJ is a "3 link" type set up and the JK is a 5 link.

Here is a picture of the WJ rear suspension. (Stock)
