OVRLND CAMPERS ONLY : Post your OVRLND Camper build here or a link to your build thread to inspire others!

[FJWillis]

I started with 35 lb struts (the strongest OVRLND had at the time I bought the camper), then I switched to 45 lb struts when I added solar and a couple of Maxtrax to the roof. I recently put 65lb struts on the back when I added two more Maxtrax. I kept 45 lb struts on the front. It works perfectly for me.

This is good information. Thanks so much!



[Peter_n_Margaret]

Linear actuators are an alternative to gas struts for some jobs.
All sorts of lengths, powers and speeds available. Put the switch wherever you want or even make them remote controlled.

Cheers,
Peter
OKA196 motorhome



[Peter_n_Margaret]

I have gas struts on our pop-top.
They are 700Nm (157Lbs Force), whch is more than they need to be. They are also longer than they need to be. The actual mechanical advantage can be adjusted by adjusting the angle. There are multiple attachment points at the bottom end of each gas strut to allow for this.
The pop-top is easily put up or brought down from inside. The longer-than-necessary struts keep the fabric tight when it is up.
If I add some weight to the top, I simply move the lower attachment point to compensate.




Cheers,
Peter
OKA196 motorhome



[crolison]

Anybody looking for a camper for a tundra/f150 6.5' bed?

Have mine up for sale fully loaded, but willing to sell stripped

C

Thread 'FS: OVRLND Camper - Tundra/F150 6.5' bed + build'

Dec 17, 2025

OVRLND Camper - tundra 6.5' bed

Factory options:
Lift struts
Extra rear door room
Driver flip up hatch
Passenger flip up hatch
Extra bedding
Camper Jack mounts (experimental from Ovrlnd)
Rhino rack roof rails
Maxxair fan
3" bifold medium firm mattress
Lower 8020 rail
Headliner custom duck fabric
Extra reinforcement / structural members for propane/jerry can
At overland Jerry can mount
Propane mount
Awning mounts both sides
Solar port

Build out/heat:
Propex hs2800 with digital display + propane alarm
Co alarm
Dual outlet heat
Propex marine dual inlet/exhaust

Awnings:
Arb 2.0x2.5 with...

• crolison
• Replies: 5
• Forum: Expedition Campers and Trailers

Located in Denver metro



[RealRigsRattle]

Build update pics are rolling in!



[2Toyotas]

Thanks.



[dstefan]

Build update pics are rolling in!
View attachment 904332View attachment 904333View attachment 904334

I like the white with black trim!



[RealRigsRattle]

I like the white with black trim!

Thanks! Hopefully it looks good on a white truck with black wheels



[Cbrappin]

Finishing up my build on our “Bread and Butter” OVRLND camper. It’s sits on a 2001 F350. The framing for the build out is welded steel tubing paneled in HDPE. Walls are insulated with an 3m product and paneled in “bubble X.” 400w of solar and a lithium batt to power a water pump, 12v fridge, vent fan, diesel heater, and some 12v and USB outlets.
