I was just thinking how many of you would be interested if I could get dirtworks to sell a more complete bumper just for our trailers? I can see if he could match my modifications during the build process and sell it with the mounts on it. You would still have to Weld two tabs on the trailer in theory for extra support. I just don't want to bug him if there's only a couple people
Smittybilt Scout Trailer Reviews?
- Thread starter Tkhawk
- Start date
I think it would depend on the cost of course. Thanks for the offer at least!
I assume close to his original price as the alterations are not a big change in material or labor.
XJ/Cherokee Rear Bumper/Tire Carrier | TheDirtworx
Bumper is 3/16" wall thickness fully enclosed box steel. D-ring mounts are 3/4” thick. Hitch is real class III seamless hitch tube. Pivot point has grease fitting and o-ring grease seals. Holds up to a 37” tire. Mounts up to the same mounting points as trailer hitch. Trail basket assembly and/or...
www.thedirtworx.com
Basket
Trail basket assembly
Trail basket assembly for use with Dirtworx tire carriers. Includes Hi-lift jack mount. Basket measures 36 x 18 x 5. Quick and easy to install and remove from tire carrier. Proudly made in the U.S.A.
www.thedirtworx.com
mmrocek
Observer
It's and ARQ270 that I bought about 5 years ago. It is very lightweight compared to the OVS270 but provides great shade and does not require legs when deployed. I have both and I did not want to mess with welding on extra supports for the OVS270 on the trailer, due to it's weight, so I just put the OvS on my excursion.
iamstyr
New member
I assume close to his original price as the alterations are not a big change in material or labor.
XJ/Cherokee Rear Bumper/Tire Carrier | TheDirtworx
Bumper is 3/16" wall thickness fully enclosed box steel. D-ring mounts are 3/4” thick. Hitch is real class III seamless hitch tube. Pivot point has grease fitting and o-ring grease seals. Holds up to a 37” tire. Mounts up to the same mounting points as trailer hitch. Trail basket assembly and/or...
Basket
Trail basket assembly
Trail basket assembly for use with Dirtworx tire carriers. Includes Hi-lift jack mount. Basket measures 36 x 18 x 5. Quick and easy to install and remove from tire carrier. Proudly made in the U.S.A.
I'd be interested as well.
Catalanbull
Member
I'm in too.
I just spoke to him and he said he would be fine with modifying it. Sounds like the only thing you would need to do is Weld a tab to the trailer next to the D rings if you wanted to but to be honest as long as you don't put a trailer behind your trailer it should be fine. The stock weight specs for the dring mounts on the trailer and hitch weight should be plenty to hold the bumper.
I'm sending him the specs today so I imagine in the next 2-3 weeks or so you guys could hit him up and order some.
I'll update if I find out anything else.
I'm sending him the specs today so I imagine in the next 2-3 weeks or so you guys could hit him up and order some.
I'll update if I find out anything else.
Catalanbull
Member
That's amazing, thanks Garrett! Looking forward to that. I'll purchase it for sure.
Catalanbull
Member
How did you mount the ARK Jacks at the back, did you build those brackets?
Not a problem, glad to help.
I chopped up the stock mount since it's an odd ball size and you can't buy that size square tubing. Then I welded it all together and painted it. Works good and I can flip them to the opposite sides upside down for more clearence if needed (so handle is towards the wheel and the jack would face straight up).
You can see where I cut the stock mount. Then I cut a 45 out of the remaining stock bracket to add a little support.
Note that most of the metal on this is galvanized and needs to be sanded before Welding. Also Welding galvanized releases harmful gasses so protect yourself accordingly. I held my breath until I almost passed out and then walked away. Similar to safety squinting... all joking aside don't breathe that stuff in.
I chopped up the stock mount since it's an odd ball size and you can't buy that size square tubing. Then I welded it all together and painted it. Works good and I can flip them to the opposite sides upside down for more clearence if needed (so handle is towards the wheel and the jack would face straight up).
You can see where I cut the stock mount. Then I cut a 45 out of the remaining stock bracket to add a little support.
Note that most of the metal on this is galvanized and needs to be sanded before Welding. Also Welding galvanized releases harmful gasses so protect yourself accordingly. I held my breath until I almost passed out and then walked away. Similar to safety squinting... all joking aside don't breathe that stuff in.
Attachments
Catalanbull
Member
Nicely done! That's really cool.
OverlandRookie
New member
For almost $9K I’m having a bunch of little issues with my trailer. I haven’t even brought it on the trail yet. The springs in my silver T-handle locks came out. The tongue box lock can’t be locked since there is too much play and you can wiggle it open (even when it’s locked). I got a replacement for the tongue box lock but same issue. Too much play and won’t secure.
I even had to add spacers to the drawer lock so it would function.
Have any of you had the same issues? Did SB help or did you have to find your own solution? Fabrication? If you buy a Honda Civic, the dealer generally doesn’t say 2 out of 4 door locks isn’t too bad.
Thanks for all the ideas on everyone’s build. There’s a ton of info here.
locked position
upright locked position
drawer spacer
locked position with lots of play
Sent from my iPhone using Tapatalk
I even had to add spacers to the drawer lock so it would function.
Have any of you had the same issues? Did SB help or did you have to find your own solution? Fabrication? If you buy a Honda Civic, the dealer generally doesn’t say 2 out of 4 door locks isn’t too bad.
Thanks for all the ideas on everyone’s build. There’s a ton of info here.
Sent from my iPhone using Tapatalk
